Single Component
Oil Soluble
Polyurethane Grouting Fluid
—
One-component polyurethane grout (Oil-soluble) is a kind of chemical grout material, which is formed by composite polymerization of polybasic alcohol and polybasic Isocyanate with isocyanate groups at the end. The material reacts with water immediately to produce gas, volume expansion and the formation of a water-insoluble and has a certain strength of the foaming body, can be waterproof leakage, more suitable for reinforcement.
This product is produced by our company through the introduction of advanced foreign technology. Polyurethane grouting material is a kind of high elasticity and toughness gel with low shrinkage and compact structure, which is polymerized after mixing with water and then rapidly foamed, expanded and solidified. This product has a very superior self repairing function by repeatedly foaming with water, and its waterproof and leak stopping effect is 2-3 times that of traditional leak stopping materials.
Polyurethane Grouting Fluid · Grouting Material · Made In China
Product Features
—
1. Low viscosity, rapid foaming expansion after encountering water.
2. Fast foaming, high strength, no shrinkage.
3. Super-structure reinforcement, high expansion rate, good toughness, no shrinkage.
4. Suitable for single liquid high pressure grouting machine and other machines.
Fill the air leakage of the base material in the form of grouting,and treat the leakage problem from the root cause.
Under the action of the pressure of the grouting equipment,the penetration range can reach 3 meters, so there is no need for dense needles
Polyurethane Grouting Fluid · Grouting Material · Made In China
Strengthened Oil Based Polyurethane Grouting Material.
Foam Eoually, High Density And Non Shrinking.
—
Polyurethane Grouting Fluid · Grouting Material · Made In China
Performance
—
Industry standard: JL/T2041-2010
| Number | Test Items | Standard Regulations | Inspection results | Single item evaluation |
| | Project Name | Unit |
| 1 | Appearance | | Uniform Liquid,No Impurities,Non Layered | Qualified |
| 2 | Density | g/cm3 | ≥ 1.05 | 1.132 | Qualified |
| 3 | Solidify time | s | ≤ 500 | 450 | Qualified |
| 4 | Non-Volatile Content | % | ≥ 78 | 83 | Qualified |
| 5 | Viscosity | mPa.S,25℃ | ≤ 200 | 180 | Qualified |
| 6 | Frothing percentage | (%) | ≥ 1600 | 2300 | Qualified |
| 7 | Compressive strength | MPa | ≥6 | 10 | Qualified |
Central control indicators
—
Take 25g of the sample and pour it into a 450ml paper cup. Add 1g of water and stir quickly until foaming begins. Start timing when the foam height no longer rises. Stop timing when the foam height stops rising. If the height from the cup mouth to the top of the foam is greater than 3cm and the foaming time is 3min to 9min, and the foam does not shrink after 30min, it is judged as qualified.
All picking indicators
—
| Serial | Testing items | Ⅰ | Ⅱ | Ⅲ |
| 1 | Appearance | Uniform Liquid, No Impurities,Non Layered, |
| 2 | Viscosity(mPa.S,25℃ ) | 100 ～ 200 | 100 ～ 200 | 100 ～ 250 |
| 3 | Density(g/cm3) | 1.05 |
| 4 | Coagulation time (s) | 180 ～ 540 |
| 5 | Non-volatile content(%) | 78 | 78 | 80 |
| 6 | Frothing percentage(%) | 1000 |
Polyurethane Grouting Fluid · Grouting Material · Made In China
Application
—
1. Fill Tunnel, Subway, dam, basement and other cracks, the actual masonry of all the contact surface.
2. It can be used for injection in hydraulic fracture, and it can be used with catalyst to finish foaming quickly. Contact with the water can be fully expanded foam, effective water plugging, reinforcement and reinforcement.
Note
—
1. Wear protective equipment (such as gloves, goggles) during construction to avoid direct contact with the skin, if there is contamination should be washed with plenty of water.
2. This product is stored in a cool place, construction must pay attention to ventilation and away from the source of fire materials not solidified before the construction area away from open fire.
Polyurethane Grouting Fluid · Grouting Material · Made In China
Product packaging
—
1. Stored in clean, dry and sealed iron drums
2. Transport according to regular product requirements, prevent rain, exposure, squeezing, and collision, and ensure that th packaging is intact.
3. The product should be stored in a ventilated, dry and cool place, away from direct sunlight and rain. The storage temperature should not be higher than 40℃.
4. Under normal storage conditions, the shelf life is 9months.
Polyurethane Grouting Fluid · Grouting Material · Made In China
FAQ
—
Q:Are you a factory or trading company?
We are a factory.
Q:Where is your factory located? How can I visit there?
Our factory is located in Huai'an City, Jiangsu Province, China. All our clients, from home or abroad, are warmly welcome to visit us!
Q:Can I get some samples?
Yes, we can supply the free sample, but the shipping cost be paid by our customers.
Q:Can you accept small order?
Yes.
Q:What is term of payment?
1) 30%T/T down payment and balance against the copy of B/L;
2) or 100% L/C at sight.
Q:How about delivery leadtime?
About 7-14 days after payment confirmed. (Except Chinese holiday)
Which port will be used as loading port?
Nanjing Port or Shanghai Port.
How to confirm the Product Quality before placing orders?how can we guarantee quality?
You can get free samples for your testing.We can manufacture the products according to your specific requirment. Always a pre-production sample before mass production;
Always final Inspection before shipment;
Q:How about import customs fee?
A:Our sales will declare the value as customer's require normally. Import duties, taxes and charges are not included in the itemprice or shipping. These charges are the buyers' responsibility. Please check with your country customs office to determine what these additional cost will be prior to bidding/buying. If the goods were turned back or destroyed for unable ustoms-clearance, the related cost will be paid by customers.
Polyurethane Grouting Fluid · Grouting Material · Made In China
About Us
—
Jiangsu Lihong Technology Development Co., Ltd. is a national high-tech enterprise integrating R&D, production, sales and technical services. The company is located in the Salt Chemical New Materials Industrial Park in Huai'an City, Jiangsu Province, covering an area of 150 acres. The total investment of the factory exceeds RMB 500 million. Currently, there are 14 production lines that lead the industry with independent innovation, with an annual production capacity of more than 100,000 tons.
The company is the key laboratory of green polyurethane materials in Huai'an City, a national high-tech enterprise, a specialized and innovative small and medium-sized enterprise in Jiangsu Province, a private technology-based enterprise in Jiangsu Province, and a member unit of the China Polyurethane Industry Association.
